LDAP setup for Grafana

This section applies only to OpsVerse Private SaaS deployments.
Create a secret in the namespace where the Observability stack is installed using the following example as a reference:
YAML
apiVersion: v1
kind: secret
metadata:
  name: ldap-config
data:
  ldap.toml: |-
      [[servers]]
      # Ldap server host (specify multiple hosts space separated)
      host = "ldap"
      # Default port is 389 or 636 if use_ssl = true
      port = 389
      # Set to true if ldap server supports TLS
      use_ssl = false
      # Set to true if connect ldap server with STARTTLS pattern (create connection in insecure, then upgrade to secure connection with TLS)
      start_tls = false
      # set to true if you want to skip ssl cert validation
      ssl_skip_verify = false
      # set to the path to your root CA certificate or leave unset to use system defaults
      # root_ca_cert = "/path/to/certificate.crt"
      # Authentication against LDAP servers requiring client certificates
      # client_cert = "/path/to/client.crt"
      # client_key = "/path/to/client.key"

      # Search user bind dn
      bind_dn = "cn=admin,dc=example,dc=org"
      # Search user bind password
      # If the password contains # or ; you have to wrap it with triple quotes. Ex """#password;"""
      bind_password = 'admin'

      # User search filter, for example "(cn=%s)" or "(sAMAccountName=%s)" or "(uid=%s)"
      # Allow login from email or username, example "(|(sAMAccountName=%s)(userPrincipalName=%s))"
      search_filter = "(uid=%s)"

      # An array of base dns to search through
      search_base_dns = ["ou=People,dc=support,dc=example,dc=org"]

      # group_search_filter = "(&(objectClass=posixGroup)(memberUid=%s))"
      # group_search_filter_user_attribute = "distinguishedName"
      # group_search_base_dns = ["ou=groups,dc=grafana,dc=org"]

      # Specify names of the ldap attributes your ldap uses
      [servers.attributes]
      name = "givenName"
      surname = "sn"
      username = "cn"
      member_of = "memberOf"
      email =  "email"
apiVersion: v1
kind: secret
metadata:
  name: ldap-config
data:
  ldap.toml: |-
      [[servers]]
      # Ldap server host (specify multiple hosts space separated)
      host = "ldap"
      # Default port is 389 or 636 if use_ssl = true
      port = 389
      # Set to true if ldap server supports TLS
      use_ssl = false
      # Set to true if connect ldap server with STARTTLS pattern (create connection in insecure, then upgrade to secure connection with TLS)
      start_tls = false
      # set to true if you want to skip ssl cert validation
      ssl_skip_verify = false
      # set to the path to your root CA certificate or leave unset to use system defaults
      # root_ca_cert = "/path/to/certificate.crt"
      # Authentication against LDAP servers requiring client certificates
      # client_cert = "/path/to/client.crt"
      # client_key = "/path/to/client.key"

      # Search user bind dn
      bind_dn = "cn=admin,dc=example,dc=org"
      # Search user bind password
      # If the password contains # or ; you have to wrap it with triple quotes. Ex """#password;"""
      bind_password = 'admin'

      # User search filter, for example "(cn=%s)" or "(sAMAccountName=%s)" or "(uid=%s)"
      # Allow login from email or username, example "(|(sAMAccountName=%s)(userPrincipalName=%s))"
      search_filter = "(uid=%s)"

      # An array of base dns to search through
      search_base_dns = ["ou=People,dc=support,dc=example,dc=org"]

      # group_search_filter = "(&(objectClass=posixGroup)(memberUid=%s))"
      # group_search_filter_user_attribute = "distinguishedName"
      # group_search_base_dns = ["ou=groups,dc=grafana,dc=org"]

      # Specify names of the ldap attributes your ldap uses
      [servers.attributes]
      name = "givenName"
      surname = "sn"
      username = "cn"
      member_of = "memberOf"
      email =  "email"
﻿
To configure OpsVerse ObserveNow Grafana to use this new Azure AD Config, login to the OpsVerse Admin Console, navigate to your ObserveNow stack, enable LDAP Authentication, and add the name of the secret which you created in the previous steps.
You can also work with the OpsVerse Support Team to configure your Grafana instance to use LDAP for authentication or if you have any other customization requirements.
﻿
